INTELLIGENT LED
Minleon's TrikLits – G28
In association with BlueHopper
Minleon’s flagship RGB strand, is individually controllable 2 x RGB(W) pixels for nice even colors and brightness. Your favorite Meshtek or Minleon stock controllers create smooth effects with a 16-bits per channel.Sturdy, professional and commercial construction with insulated wire for 4-season, permanent installations. Custom lengths and pitches available in 3 different diameter bulbs.
Options
LEDs/channels: RGB or RGBW
Pixel spacing: 4″, 6″ or 12″
Light counts: 5, 10, 25, or custom with MOQ
Wire color: black, green, white
Dimming curve: 16-bit (RGB+) or 8-bit (RGB-SE)
Thru connector: female thru or terminated with eye-hole loop
Features and Advantages:
4-inch Controllable Cubes
Smooth 16-bit Dimming
Slick Video Appearance
MeshTek & BlueHopper Compatible
Customizable Lead Wire
Multiple Wire Colors
General Specifications:
Output
LED Type
SMD5050
LED Channels
R-G-B
LED Count
16-bit, 65,536 dimming levels*
LED Quantity
2
Viewing Angle
360-degrees
Control
Individually Addressable
yes
Control Systems
MeshTek 1-Port and 4 Port Controllers with BlueRoots App
Max Lights before power injection
approx. 125L
Max Distance before Power Injection
approx. 100-feet
Electrical & Safety
Input Voltage
12 VDC
Current
0.028 Amps
Power
0.336 Watts
Wire
22 AWG, 3C, UV protected
Inline power injection
via Minleon Power T+’s & RGB+5A-12V
Certifications
(c)UL listed, CE
Physical
Diameter
28mm
Weight
approx. 0.04 lb.
Housing
polycarbonate
Bulb Style
frosted
Connector Type
LLT twist-lock
Operating Temperature
Neg -20 to +50 Cel. / Neg -4 to +122
Far
